Welcome to Paint Stripers. Experts in the Parking Lot Striping business with over 30 years of experience.

The Trueline family of paint stripers are rugged, affordable and capable machines. And most of all they are trusted to do the job when other machines breakdown or fail. They are the best priced commercial machines on the market and fully capable of doing commercial work. Because the stripers are built with simplicity in mind, any one can work on the machine and downtime is near zero. Trueline Stripers have been built by Trusco Manufacturing since 1964. The company has an excellent reputation for service and quality. We use their machines in our operation and highly recommend them to our customers. Please contact me at steve@colebrothers.com or 850-934-3157 with any questions.

Trusco Trueline Model 20 Parking Lot StriperHere is how a Trueline Striper works. The striping machines utilize a stainless steel pressure tank. Air pressure is used to force, thinned paint out of the tank and into a spray tip that is housed in a paint box that slides along the ground. The spray tip creates a flat, fan pattern spray that hits the edges of the box and creates a clean, sharp, line. (The box makes it possible for the machine to produce a nice clean line even in windy conditions.)  Each machine uses a different method for pressurizing the tank but all stripe the same way.  One other nice feature is that all the machines are quiet.  Even the T2000 gasoline model only needs to run  to pressurize the reserve tanks.  Once the tanks are pressurized you can turn off the engine and stripe quietly.  This is important because you need to be able to hear what is going on around you.

Trueline machines can be used to stripe factory floors, parking lots, roads, and sports fields.  You don’t need a machine for each job.  One machine will do all four.

We have several Trueline models for you to choose from. Each has its own unique characteristics and capabilities and is designed to fit your specific needs. We have an information and ordering page for each machine accessable via the links below or to the right. The information page goes into more depth about the features and advantages of each machine. The available Trueline machines are as follows

Models Available:
Model 20 – 4 gallon pump up striper – $1,010

Model 20 PLUS – 4 gallon pump up striper w/ air valve – $1,070
Model 250 APT (For companies or factories that have access to compressed air) $2,110
Model 250 or 350 N (Nitrogen High Pressure Cylinder) $1,870 / $2,370
Model 250 or 350 BP (Battery Powered) – $2,232 / $2,823
Model 250 or 350 EC (Plug in electric air compressor) $2,324 / $2,824

The following Accessories are available for all machines except the model 20:

  • Spray gun
  • Glass Bead Dispenser
  • Solvent Cleaning System
  • Double Line Attachment

The following specifications are common to all models:(except model 20):

  • Welded heavy duty iron steel frame with 5/8″ axles.
  • 10″ pneumatic tires, heavy duty steel hub, steel ball bearings.
  • 4″ Spray Box – Heavy Duty Steel. Other box sizes available.
  • Drain hose to make cleanup a quick easy clean job.
  • Eight quart galvanized funnel with aluminum strainer.
  • Tank Brush for cleaning the inside of paint tank.
  • Parking Brake to keep the machine from rolling down hills
  • Simple viscosimeter to measure the paint thickness.
  • Fittings are made from Brass & stainless steel
  • 98% assembled – Within 30 minutes you should be ready to stripe.
  • 30 day satisfaction guarantee warranty
  • 2 year warranty on defective parts and workmanship.
  • 10 year warranty on rust through of tank or chassis.

If you are looking for a very economical way to stripe factory floors, parking lots, roads or sporting fields then the Trueline Paint Striper is a machine to look into.
